| 品牌 | 铭俊源泵业 | 型号 | 80WFZB-BD | 材质 | 不锈钢 |
| 驱动方式 | 电动 | 用途 | 化工泵 | 泵轴位置 | 边立式 |
| 叶轮结构 | 封闭式叶轮 | 叶轮数目 | 单级 | 叶轮吸入方式 | 单吸式 |
| 原理 | 离心泵 | 性能 | 不阻塞 | 扬程 | 15（m） |
| 转速 | 2900（r/m） | 功率 | 5500（w） | 流量 | 15（m3/h） |
| 规格 | 流量1-800 m3/h,扬程5-150m,转速14050-2900r/min | 适用范围 | 特别适用于含化工杂质、污水杂质、油气水混合杂质的液体广泛应用于电力、化工、冶金、医药、食品、环保、市 |
WFB型无密封自控自吸泵产品概述
WFB typeself controlling self-priming pump without sealingproduct overview
WFB 系列单级单吸、单级多吸立式特种无密封自控自吸泵，是引进国外先进技术，消化吸收、研制开发的新型产品。，且能够耐温、耐压、耐磨、“一次引流，终生自吸”。目前生产有不锈钢、增强聚丙烯、碳钢、铸钢、铸铁等多种材质的系列产品。采用多面离心动态密封装置，除去了传统水泵的填料密封、盘根密封、机械密封、彻底制服了“跑、冒、滴、漏”，是替代各种潜水泵、潜污泵等最理想的设备，在电力、化工、冶金、医药、食品、环保、市政、消防、民用、建筑等行业中广泛应用，深受用户好评。
WFB series singlestage single suction,single stagemultiplesuction verticalspecialself controlling self-priming pump without sealing,is the introduction of foreign advanced technology,the digestion and absorption ofnewproducts,research and development of the.Temperature,pressure,and can,wear-resisting,"a drainage,life-long self-priming".The current productionof stainless steel,reinforcedpolypropylene,cast steel,carbon steelseries products,cast ironand other material.By using multicentrifugal dynamicsealing device,removethe traditional pump packing seal,packing seal,mechanical seal,completely subdued,"run,run,drip,leak",is theequipment to replac thevarioussubmersible pump,submersible sewage pumps ideal,widely used inelectric power,chemical industry,metallurgy,medicine,food,environmental protection,municipal,fire,civil,constructionand other industries,well received by users.
WFB型无密封自控自吸泵产品特点
WFB typeself controlling self-priming pump without sealingproduct features
WFB型无密封自控自吸泵优越的自控功能，可与高科技领域内的高自动化系统配套使用，移动方便，拆卸简便，易于安装输送流量1-800 m3/h ，扬程5-150m，转速14050-2900r/min
WFB typeself controlling self-priming pump without sealingsuperiorautomatic controlfunction,andhigh-techin the field ofhighautomation systemsupporting the use,convenient moving,easy disassembly,easy installation andtransportation flow1-800m3/h,headof 5-150m,speed 14050-2900r/min
WFB型无密封自控自吸泵产品用途
WFB typeself controlling self-priming pump without sealingproduct use
WFB型无密封自控自吸泵产品特别适用于含化工杂质、污水杂质、油气水混合杂质的液体广泛应用于电力、化工、冶金、医药、食品、环保、市政、消防、民用、建筑等行业中。
WFB typeself controlling self-priming pump without sealingproductsespecially suitable for containingchemicalimpurities,sewageimpurities,oil gas watermixedliquid impuritiesare widely used in electric power,chemical industry,metallurgy,medicine,food,environmental protection,municipal,fire protection,civil,construction and other industries.
WFB型无密封自控自吸泵性能参数《参数太多，具体欢迎来电咨询沟通 铭俊源泵业韦先生13670159240》
| 规格型号 | 转速 r/min | 流量 m3/h | 总扬程 M | 配套功率kw | 允许吸深≤M | 吸液口径MM | 出液口径 MM | 整机重量 kg | ||||
| 类别代码 | 材质代号 | 型号 | ||||||||||
| 1—5 | T.G.PP.BXG | 16WFZB-A | 2900 | 0.75 | 8 | 0.75 | 2.5 | 16 | 10 | 75 | ||
| 1.1 | 6.5 | |||||||||||
| 1.5 | 5.5 | |||||||||||
| 1—5 | T.G.PP.BXG | 32WFZB-A | 2900 | 4.5 | 13 | 1.5 | 3 | 32 | 25 | 99 | ||
| 6.5 | 10.5 | |||||||||||
| 9 | 8 | |||||||||||
| 1—5 | T.G.PP.BXG | 40WFZB-A | 2900 | 6.5 | 25 | 4 | 4 | 40 | 32 | 140 | ||
| 8.5 | 23 | |||||||||||
| 10 | 21 | |||||||||||
| 1—5 | T.G.PP.BXG | 40WFZB-A1 | 2900 | 13.5 | 18 | 3 | 4 | 40 | 32 | 140 | ||
| 5 | 15 | |||||||||||
| 8 | 13 | |||||||||||
| 1—5 | T.G.PP.BXG | 40WFZB-A2 | 2900 | 10 | 11 | 2.2 | 4 | 40 | 32 | 125 | ||
| 14 | 8 | |||||||||||
| 1—5 | T.G.PP.BXG | 50WFZB-A | 2900 | 7.5 | 28 | 5.5 | 5 | 50 | 40 | 205 | ||
| 12.5 | 26 | |||||||||||
| 15 | 24.5 | |||||||||||
| 1—5 | T.G.PP.BXG | 50WFZB-A1 | 2900 | 10.5 | 20.5 | 3 | 5 | 50 | 40 | 170 | ||
| 1—5 | T.G.PP.BXG | 50WFZB-AD | 1450 | 5 | 11 | 1.5 | 4 | 50 | 40 | 149 | ||
| 6.3 | 10 | |||||||||||
| 7.5 | 9 | |||||||||||
| 1—5 | T.G.PP.BXG | 50WFZB-AD1 | 1450 | 10 | 6 | 1.5 | 4 | 50 | 40 | 149 | ||
| 1—4 | T.G.BXG | 50WFZB-B | 2900 | 10 | 40 | 11 | 5 | 50 | 40 | 215 | ||
| 11 | 38 | |||||||||||
| 15 | 35 | |||||||||||
| 1—4 | T.G.PP.BXG | 50WFZB-B1 | 2900 | 7 | 33 | 7.5 | 5 | 50 | 40 | 205 | ||
| 12 | 31 | |||||||||||
| 15 | 29 | |||||||||||
| 1—5 | T.G.PP.BXG | 50WFZB-B2 | 2900 | 10 | 26.5 | 4 | 5 | 50 | 40 | 185 | ||
