柴油机拖车泵 高效自吸柴油机泵Pump Diesel Engine

品牌	其他	型号	P型自吸泵	材质	铸铁
驱动方式	电动	用途	排污泵	泵轴位置	卧式
叶轮结构	敞开式叶轮	叶轮数目	单级	叶轮吸入方式	单吸式
原理	离心泵	性能	不阻塞	扬程	10-80（m）
转速	1450-2900（r/m）	功率	3-220 KW（w）	流量	8-1200（m3/h）
规格	高效自吸排污泵

￥1400.00 已售出8346件 ￥1300.00 已售出1148件 ￥890.00 已售出7840件 ￥1500.00 已售出3835件 ￥145.00 已售出3368件 ￥920.00 已售出5861件 ￥1450.00 已售出2682件 ￥2150.00 已售出9190件

SpecificationsPump Diesel Engine With Trailer/Diesel Self-Priming Non-Clogging Sewage Pump Set/Hose Pump/Water Pump Set
Flow : 46-1275m3/h

Pump Diesel Engine With Trailer/Diesel Self-Priming Non-Clogging Sewage Pump Set/Hose Pump/Water Pump Set

Operation condition

1.The temperature of medium no more than 80oC,the density of medium is1.0 ~ 1.3*103Kg/m3,PH is within 5~9,

2.Max diameter of solid should be less than 75mm,

3.Max suction lift no more than 7m

Usage:

1.Municipal Project, Sewage Project, Instruction Project

2. Transportion of the sewage of uptown

3.Sewage transportion in Hospital,hotel and so on

4.Classification of municipal sewage treatment factory and concentrate treatment systems engineering.

5. Transportation of the factory and contaminated water

Character
1.Drive by diesel engine (water cooled,air cooled) or motor
2.Self priming

3.can equipped withtrailer (two wheel or four wheel)
4.Good quality and low price

Specification

1. Inlet & Oulte: 2'' 3'' 4'' 6'' 8'' 10'' 12''

2.Impeller Diameter: 158.75-457.2mm
3.Rotary Speed: 650-2900r/m4.Flow rates: 46-1275m3/h5.Head: 33-62m6.Motor / diesel engine: 1HP-125HP7.N.W: 500KG-1550KG8.G.W: 800KG-1950KG9.Max Solid: 20.63-76.2mm

10.metarial: cast iron

11.Package: plywood case

CE certificate
